Menu 2
Feature # Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 Engine checking
Virtual
tach
voltage Off tachometer
2 Remote Start Engine
Runtime
12 min
24 min 60 min
3 Park light output Pulsed
Constant
4 Cranking time
0.6 sec
.
0.8 sec. 1.0 sec. 1.2 sec. 1.4, 1.6, 1.8, 2.0, 4.0
sec
5 Activation pulse count
1 pulse
2 pulses 3 pulses
6 2nd Ignition/Acc
behavior
Ignition
Accessory
7 Accessory output
Off during
wait-to-
start
On during
wait-to-start
8 Status behavior
Normal
Latch rear
defogger
Pulse rear
defogger
9 Diesel wait-to-start
timer
Off
Timed 15 sec Timed 30
sec.
Timed 45
sec.
10 Virtual tach fine tune
0 (as
learned)
100ms to 1 sec ( in 100 ms increments)
11 Timer mode run time
12 min
3 min 6 min 9 min
1. Engine checking
1. VirtualTach: battery voltage drop/rise during cranking determines when the starter output is
released. During runtime, constant voltage level is monitored to determine if the engine is running.
2. Voltage: starter output during cranking is a programmed duration (Set in Cranking Time). During
runtime, constant voltage level is monitored to determine if the engine is running.
3. Off: starter output during cranking is a programmed duration (Set in Cranking Time). The remote
start keeps the ignition/accessories active for the programmed runtime whether the engine is running
or not.
4. Tachometer: tach input signal during cranking and runtime determines when the starter output is
released and if the engine is running.
2. Engine Runtime
• 12/24/60 minutes: sets engine runtime during normal remote start operations.
3. Park light output
1. Pulsed: the lights will pulse on/off during remote start.
2. Constant: the lights will turn on solid during remote start.
4. Cranking time
• 0.6/0.8/1.0/1.2/1.4/1.6/1.8/2.0/4.0 seconds: determines the starter output duration during
cranking for the ‘Voltage’ and the ‘Off’ Engine Checking Mode options.
5. Activation pulse count
• 1/ 2/ 3 pulses: sets the number of remote control commands received or Activation Input required
to activate and de-activate remote start.
6. 2nd Ignition behavior
1. Ignition 2: the relay will emulate the Ignition 1 output during remote start.
2. Accessory 2: the relay will emulate the Accessory 1 output during remote start.
