Wiring Diagram
Status LED
Control button
Menu
Wheel
Menu
Wheel
Menu
Wheel
Control Center 6711T
4x04
Neutral Safety
Switch
D2D Port (for external
Xpresskit interface module)
ON
IMPORTANT! Neutral Safety
switch must be plugged in
and in the ON position
RF Port
for IVU
Control Center
Thermistor/Temp Sensor
Bitwriter/SmartStart Port
Door Lock
Port
Remote Start
8-pin Harness
Main 6-pin
Harness
10A FUSE
MINI ATM
RPN: 8540
LIGHT FLASH POLARITY
(10A (MAXIMUM) FUSE JUMPER)
Aux/Shutdown/Trigger 24-pin Harness
Horn Input
Polarity Jumper
+ -
1 3 5
INSERTION/WIRE SIDE
2 4 6 24
23PINK/WHITE VIOLET/WHITE
GREEN/WHITEBLACK/WHITE
