9
© 2011 Directed Electronics. All rights reserved.
Startup Diagnostics: If the vehicle fails to activate the remote start, the remote start module will notify you via
your Responder LC3 2-way remote control and will flash the parking lights on the vehicle to notify you of what
caused the no-start situation.
Parking Light Flashes
5 flashes Brake wire is active
6 flashes Hood pin wire is active
7 flashes Manual transmission mode is enabled and not initialized.
8 flashes Neutral safety wire has no ground or the neutral safety switch is Off.
Remote Pairing
Prepare the vehicle system to be Paired with a new remote
1. Turn the key to the ON position.
2. Within 5 seconds press and release the Control button on the Control Center one time.
3. Within 5 seconds, press and hold the Control button on the Control Center. The status LED will flash one
time and the horn then honks to confirm the vehicle is ready for remote pairing.
4. Release the Control button and proceed below.
Note:
If no remote pairing results, the system will exit after 60 seconds.
Prepare the LC3 2-way remote control to be Paired with the system:
Remote Pair matches your LC3 remote to the system. Make sure the LC3 remote is set for the desired Car 1
(Default) or Car 2 operation for the system it will be paired with.
1. Press and hold the
button for 8 seconds (If Car 2 mode is on, ignore the Car Select beep after 3 sec-
onds) until the main menu appears.
2. Press and release the
button until
Remote Pair
text is displayed.
3. Press and release the
button until
Pair
text is displayed.
4. Press and hold the
button until tones are played on the LC3 remote.
5. Successful or Failed Pair: The LC3 remote control indicates a successful or failed pairing on the display.
Prepare the vehicle system to be Paired with the companion or a new 1-way remote as described above.
Note: If no remote pairing results, the system will exit after 60 seconds.
Prepare the companion 1-way remote control to be Paired with the system:
Make sure the remote is set for the desired Car 1 (Default) or Car 2 operation for the system it will be paired
with.
1. Press and hold the
button for 8 seconds.
Note: If Car 2 mode is on, ignore the Car Select beep after 3 seconds.
2. Wait for the Transmit LED to light solid and the remote to beep. Release the
button.
3. Press the
button for 1 second. The transmit LED will blink 3 times and beep 3 times.
4. Within 5 seconds, press the
button.
5. The vehicle horn will honk. You have now successfully learned the remote to the vehicle remote start and
keyless entry system.
6. Press the
button two times to exit learn routine on the remote. The transmit LED will turn off and exit
tone will sound.
