Feature menus
Default settings are in bold type.
Menu 1
Feature # Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 Horn function
Off
Siren
20 mS
Siren
30 mS
Siren
40 mS
Siren 50 mS
2 Ignition con-
trolled lock
On
Off
3 Ignition
controlled
unlock
On
Off
4 Doorlock out-
put duration
0.8 sec
.
3.5 sec. 0.4 sec.
5 Double pulse
unlock
Off
On
6 Double pulse
lock
Off
On
7 Factory
Alarm Disarm
function
with
unlock
Before unlock Remote start
only
8 Factory
Alarm Disarm
Pulses
Single
Double
9* Comfort
Closure
Comfort
Closure 1
Off
Comfort
Closure 2
10* Panic
On
Off
*Not available on the 1-button remote
1. Horn Function
1. Off: turns the lock/unlock horn honk output off, but Panic is still active for 60 seconds
2. On: Opt 2-5, 20-50 mS: sets the lock/unlock horn honk output duration
2. Ign-controlled Lock
1. Off: door lock output will not output when ignition is turned on.
2. On: door lock output will activate when ignition is turned on.
3. Ignition Controlled Unlock
1. On: door unlock output will activate when the ignition is turned off.
2. Off: door unlock output will not activate when the ignition is turned off.
4. Door Lock Output Duration
1. 0.8sec.: the door lock/unlock pulses for 800mS in duration
2. 3.5sec.: the door lock/unlock pulses for 3.5 seconds in duration
3. 0.4 sec.: the door lock/lock pulses for 400mS in duration
5. Double Pulse Unlock
1. Off: unlock output pulses once
2. On: unlock output pulses twice
