F. ACCESS CARD AND ACCESS CARD INTERFACE
Genie 2 has an Access Card in the Rear Panel (ref: Figure 3). The Access Card will be pre-installed in the Genie 2.
The Access Card is paired to the Genie 2 (with a Receiver ID) and can be swapped out with a new Access Card if
necessary. The Card Number is located on the back side of the card. The way to insert the card is explained with
an illustration near the card slot.
G. SPECIFICATIONS
• Storage : 2TB SATA HDD
• Dimensions:
• Height: 266mm (10.47 inches)
• Width: 154mm (6.06 inches)
• Depth: 142mm (5.59 inches)
• Mechanical housing design
• Genie 2 needs to be placed in a vertical position. Sensors will detect when the orientation is not
vertical. The Wireless LED will display Flashing Yellow, and the clients will display an On-Screen
Tilt Error Display.
Product Manual—Genie 2™
10 Version 2.0 – 4/4/2017
