C. REAR PANEL
• “POWER INPUT”: 25.2V DC power connector with power indicator LED
• “SAT IN—SWM”: One satellite input coax connector (SWiM)
• “MoCA”: One MoCA status indicator LED
• “USB”: One USB 3.0 port
• “ETHERNET”: One Ethernet port
• “eSATA”: One eSATA port
• “Access Card (SIM CARD)”: with instruction to “PUSH TO EJECT”: One Conditional Access Card slot
Do not access unless instructed by AT&T agent
FIGURE 3: Genie 2 REAR PANEL
Product Manual—Genie 2™
8 Version 2.0 – 4/4/2017
Access Card (SIM CARD)
ETHERNET
MoCA
POWER INPUT
POWER INPUT
USB
SAT IN
