7
DIRECTV Plus
®
DVR - User Guide
6) DIGITAL AUDIO OPTICAL – Provides the best digital-quality audio signal.
7) S-VIDEO – Provides the best picture quality, better than VIDEO RCA-type or RF coaxial cable
jacks. If your TV has an S-Video jack, use it along with the audio jacks (S-Video only carries picture
information, not sound) to connect to your TV.
8) VIDEO (Yellow) – Provides better picture quality than the OUT TO TV jack. Connect the second
RCA-type composite VIDEO jack to another device, such as a VCR. You must also connect the
AUDIO cables when using the VIDEO connection.
9) AUDIO (R-Red and L-White) – Audio cables off er better sound quality than RF coaxial cables. You
can connect a second set of audio cables to another component, such as a VCR or stereo.
10) PHONE – Connects the DIRECTV Plus DVR to a telephone wall jack. We require a land-based
telephone connection to communicate periodically with your DIRECTV Plus DVR.
11) AC POWER INLET – Connects the DIRECTV Plus DVR to an electrical outlet. We recommend
you use a surge protector to safeguard your DIRECTV Plus DVR from power spikes.
R16 UG Book.indb 7R16 UG Book.indb 7 10/29/07 2:51:31 PM10/29/07 2:51:31 PM
