SWiM 8 Channel Switch Installation
KaKu -95° -72.5°
4 Port Legacy Multiswitch
Single tuner SWiM compatible IRD
HD DVR SWiM compatible IRD
R-15 DVR IRDs
BBC’s are not required in this scenario
Due to size of this drawing the below items
are not shown, all installations must include
these items
Switch Drip / Service Loops
Wall Plates
Exterior Wall penetrations / Drip Loops
Black or Blue Ground
Wire Indicates # 17ga
CCS Bond
Green Bonding
Wire Indicates #
10ga Solid Copper
Bonding
“The following grounding diagrams illustrate only a few examples of ways to bond a DIRECTV system
and may not meet bonding requirements in every municipality within the United States. It is the
responsibility of the installer/technician performing the installation to know and follow all local, state
and federal grounding regulations within the area he or she is working.”
SWM
IRD
Satellite In
Phone
Out to TV
Off Air In
Video
S-Video
120V
Video
SWM-
1
8 Channel SWiM
18v
Sat 99°/
101°
13v
Sat 99°/
101°
18v/22KHz
13v/22KHz
Flex
Port
1
Flex
Port
2
Legacy
1
Legacy
2
SWM1/
PWR
SWM 2
Sat 103°/110°/119°
72.5°
LNB
95°
LNB
Weather
Cap on
Unused
Ports
Weather
Cap on
Unused
Ports
Weather Seal identifier
All Outdoor F-Connectors must
be tightened to no less than 30
inch lbs to include LNB’s
Distance between
the Power Inserter
and the SWiM
switch can not
exceed 150 ft
Legacy
1
Legacy
3
Legacy
2
Legacy
4
Legacy 4
Port
Multiswitch
SWiM
Output
Ports
LNB Input
Ports
Satellite In Ports
Phone
Out to TV
Off Air In
Video
S-Video
120V
Video
SWM-1
2
HD
DVR
18v
Sat 99°/
101°
18v/22KHz
13v
99° / 101°
13v/22KHz Flex Port 1
Flex Port 2
DC
Pass
4-Way
SWM Splitter
2-2150MHz
Legacy
2
Off-Air
Terminate
unused
Ports
Satellite In Ports
Phone
Out to TV
Off Air In
Video
S-Video
120V
Video
1
Satellite In Ports
Phone
Out to TV
Off Air In
Video
S-Video
120V
Video
1
Satellite In Ports
Phone
Out to TV
Off Air In
Video
S-Video
120V
Video
1
2
2
Weather
Cap on
Unused
Port
2
Weather
Cap on
Unused
Ports
To Next Page
