Subnetwork Installation Guidelines
Network Guide 73
1. The indicated addressing ranges group together the permitted addressing ranges for those
devices.
2. See the room device calculator spreadsheet available for download from our website to
know the permitted quantities for these controller models: VAV-Smart Room Control Device
Calculator.xlsm
3. A controller can support a maximum of two (2) Allure Series sensor models equipped with a
CO
2
sensor. Any remaining connected Allure Series sensor models must be without a CO
2
sensor.
4. These models support a recommended maximum of 4 sensors (Allure Series sensor series
and EC-Multi-Sensor series) combined in total. Each Allure Series sensor model equipped
with a CO
2
sensor counts as 2 sensors (for example, you cannot connect any other sensors
if you connect two Allure Series sensor models equipped with a CO
2
sensor or you can con-
nect up to two other non-CO
2
sensors if you connect one Allure Series sensor models
equipped with a CO
2
sensor). When a longer system response time is acceptable, up to 4
ECL / ECB-600
Series
Allure EC-Smart-Vue series 1 to 12
12
3
Allure EC-Smart-Comfort series 1 to 6
Allure EC-Smart-Air series
EC-Multi-Sensor series - Not Supported
ECx-Light-4 / ECx-Light-4D / ECx-
Light-4DALI
1 to 4
2
5
ECx-Blind-4 / ECx-Blind-4LV
2
5
ECx-4XX I/O Extension Modules 1 to 7 2
ECL / ECB-600
Models Only
ECx-Display Not applicable 1
Table 16: Subnetwork Module Compatibility and Maximum Supported Quantity Chart
Controller
Model
Subnetwork Data Bus Device
Permitted Subnet
ID Addressing
Range
1
Maximum
Quantity Allowed
The following devices use different Subnet address ranges so that the same Sub-
net ID of one device will not conflict with that of another device that is on a different
Subnet address range:
• 1 address range for Allure EC-Smart-Vue sensors
• 1 address range for Allure EC-Smart-Comfort and Allure EC-Smart-Air sensors
• 1 address range for EC-Multi-Sensors
• 1 address range for ECx-Light/Blind expansion modules
• 1 address range for ECx-Display
For example, an Allure EC-Smart-Vue sensor and an Allure EC-Smart-Air sensor
can have the same Subnet ID, but an Allure EC-Smart-Air sensor and an Allure
EC-Smart-Comfort sensor must have a different Subnet ID. Consequently, you can-
not set both an ECx-Light-4 and an ECx-Blind-4 to have a Subnet ID as 1.
