Digital/Analog Outputs
£ Digital Analog Outputs can be used as 24 VAC Triac outputs (using 24V~ / DOx pin) or as analog outputs (using AOx pin).
£ 24V~ / DOx pin and AOx pin cannot be used simultaneously on the same Digital Analog output.
£ If functional Earth is connected, digital analog output circuits will be PELV.
£ If functional Earth is NOT connected, digital analog circuits will be SELV.
Control Output Type Designation Connection Diagram
0 to 10VDC voltage output AOx
0
-
10
V
Common
AOx
COM
0 to 10VDC voltage output controlling an analog actuator powered by an
external 24VAC power source
AOx
AOx
COM
0
-
10
V
~
or
+
Actuator
or
-
24
VAC
0 to 10VDC voltage output controlling an analog actuator powered by the
controller
AOx
AOx
COM
0-
10
V
~
or +
Actuator
or -
24V~
Thermal Valve 24V~ / DOx
DOx
DOx
COM
Thermal Valves
Proportional valve: requires two Triac outputs 24V~ / DOx
DOx
DOx
COM
Proportional Valve
