1330 Operator’s Manual Trench - 47
Trench
Trench
1. Drive trencher to starting point. Move in line with planned trench.
2. Pull axle lock to lock wheels together.
3. Move throttle to half open.
4. Push boom control to lower digging boom to just above ground.
5. Push digging chain control to DIG. DIGGING
CHAIN WILL MOVE.
6. Increase engine speed to full throttle.
Moving digging teeth will cause death or serious injury. Stay away.
NOTICE:
• Keep everyone at lease 6 ft (2 m) from machine, digging boom, and its range of movement.
• Machine may move when chain starts to dig. Allow 3 ft (1 m) between end of chain and obstacle.
• Digging chain on top side of boom can catch on root or rock, forcing handlebar down suddenly.
Stand back from console and hold handlebar loosely.
EMERGENCY STOP: Release operator
presence device and turn ignition switch off.
IMPORTANT: Trenching movement is
toward you.
