Ditch Witch C24x User Manual

Specifications - 106 Cx Series Operator’s Manual
C12x
Power Train US Metric
Hydraulic ground drive: infinitely variable from zero to maximum, speed and direction controlled with
dual levers
Digging chain drive: hydraulic direct drive, lever-operated, one speed forward and reverse
Trencher drive: hydraulic direct drive
Pump drive: direct drive from engine
Spoils handling drive: mechanical, attached to and rotates with headshaft
Track
Width 7.9in 200mm
Ground pressure 3.3psi 23kPa
Hydraulic System US Metric
Dual pump total capacity @ 3600rpm 7.5gpm 28.4L/min
Pump characteristics @ 3600rpm to ground drive:
Pressure, relief valve setting 2500psi 172bar
Capacity 1.5gpm 5.7L/min
Pump characteristics @ 3600rpm to digging drive:
Pressure, relief valve setting 3500psi 241bar
Pressure 6gpm 22.7 L/min
Fluid Capacities US Metric
Fuel tank 1.6gal 6.05L
Engine oil, with filter 1.2 qt 1.1L
Hydraulic reservoir 11gal 41.6L
Hydraulic system 11.5gal 43.5L
Noise Level
This machine can generate sound levels exceeding 80dBA. Always wear appropriate hearing protection
when operating machine. Find sound power and pressure information at www.ditchwitch.com, or
contact customersupport@ditchwitch.com.

Ditch Witch C24x Specifications

General

Engine Make	Kubota
Engine Type	Diesel
Transmission	Hydrostatic
Gross Power	24.8 hp
Max Digging Depth	5 ft
Width	48 in
Horsepower	24.8 hp
Max Trenching Depth	5 ft
