Cx Series Operator’s Manual Overview - 5
Operator Orientation
Operator Orientation
1. Front
2. Right side
3. Rear
4. Left side
Operating Area
Operator should stand only in the location
shown.
IMPORTANT: Top view of machine is shown.
IMPORTANT: Top view of machine is shown.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ditch Witch C24x and is the answer not in the manual?

Ditch Witch C24x Specifications

General IconGeneral
Engine MakeKubota
Engine TypeDiesel
TransmissionHydrostatic
Gross Power24.8 hp
Max Digging Depth5 ft
Width48 in
Horsepower24.8 hp
Max Trenching Depth5 ft
