Chain, Teeth, and Sprockets
Chain, Teeth, and Sprockets
Chain and Tooth Maintenance
• Always replace sprockets at the same time as the digging chain. Sprockets and chain are designed to
work together. Replacing one without the other will cause premature wear of the new part.
• Keep digging chain sharp. Using dull, worn teeth will decrease production and increase shock load to
other trencher components. It can also cause chain stretch, which leads to premature wear and
failure.
• Maintain proper amount of tension on digging chain. Overtightening will cause chain stretch and loss
of machine performance. For correct tightening procedure, see “Digging Chain” on page 88.
• Use tooth pattern most appropriate for digging conditions. If conditions change, contact your
Ditch Witch® dealer for information about the most effective chain type and tooth pattern.
Chain Types
Chain Type Features
4-pitch Standard chain
2-pitch More teeth for smoother cutting
Alternating side bar Prevents soil compaction on chain
Bolt-on adapters Allows easy configuration changes
Shark® Chain II Versatile, little to no maintenance
Combination Provides pick and shovel effect

Ditch Witch C24x Specifications

General

Engine Make	Kubota
Engine Type	Diesel
Transmission	Hydrostatic
Gross Power	24.8 hp
Max Digging Depth	5 ft
Width	48 in
Horsepower	24.8 hp
Max Trenching Depth	5 ft
