Cx Series Operator’s Manual Specifications - 109
C16x
Operation US Metric
Vehicle speeds
Max transit forward 120fpm 36.6m/min
Max transit reverse 120fpm 36.6m/min
Digging chain speed
19K 366fpm 111.6m/min
35K 309fpm 94.2m/min
Spoils handling, single, open-end auger
Outer diameter 17” 432mm
Max operating weight 1895lb 860kg
Engine US Metric
Engine: Briggs & Stratton® Vanguard™ 16.0 small block, V-twin horizontal shaft
Fuel gasoline
Cooling medium air
Number of cylinders 2
Displacement
29.23in
3
479cm³
Bore 2.68” 68mm
Stroke 2.6” 66mm
Manufacturer’s net power rating @3600rpm (per SAE J1940) 16hp 11.9kW
Rated speed 3600rpm 3600rpm
Fuel consumption 1.33gph 5L/h
Max tilt angle* 20° 20°
* Exceeding these operational angles will cause engine damage. This DOES NOT IMPLY machine is stable to maximum angle of
safe engine operation.
Battery
310 CA, 12V, reserve capacity 30 min

Ditch Witch C24x Specifications

General

Engine Make	Kubota
Engine Type	Diesel
Transmission	Hydrostatic
Gross Power	24.8 hp
Max Digging Depth	5 ft
Width	48 in
Horsepower	24.8 hp
Max Trenching Depth	5 ft
