Controls - 22 ST37x Operator’s Manual
Graphic Display
Graphic Display
1. High exhaust temperature indicator
2. Air filter restriction indicator
3. Hydraulic fluid temperature indicator
4. Engine over-temperature indicator
5. Diagnostic message indicator
6. Glow plug indicator
7. DPF regeneration indicator
8. Engine coolant temperature indicator
9. DPF inhibited indicator
10. Hourmeter
11. Engine speed setpoint increase button
12. Engine speed setpoint decrease button
13. Menu button
14. Engine speed (RPM)
15. Throttle system state indicator
16. Service reminders button
17. Engine RPM setpoint indicator
18. Tier 4 menu button
19. Electrical system voltage
20. Engine percent load gauge
STOP
125
15 20
10
RPMx100
25
305
230
32
190
150
110
F
70
0
30
0
0.0V
Tier4
0
35
100
75
50
25
0
Engine
START UP
Load
0%
HRS
t43om026w.eps
123 4 56 7
8
9
10
11
12131415161718
19
20
