Installing and Operating Instructions
1592026000
1592026000 XW20K GB R1.0 22.02.2008.doc XW20K 5/5
Label Name Range Default Level
ALP Probe setting for temperature alarm P1÷P4
P1 Pr2
ALC Temperature alarms configuration rE÷Ab
rE Pr2
ALU MAXIMUM temperature alarm -50,0÷110°C / -58÷230°F
10,0 Pr1
ALL minimum temperature alarm -50,0÷110°C / -58÷230°F
10,0 Pr1
AFH Temperature alarm and fan differential 0,1÷25,5 °C / 1÷45°F
2,0 Pr2
ALd Temperature alarm delay 0÷255 min.
15 Pr2
dAO Delay of temperature alarm at start up 0 ÷ 23h 50 min.
1,3 Pr2
AP2 Probe for temperat. alarm of
condenser
nP; P1; P2; P3; P4
P4 Pr2
AL2 Condenser for low temperat. alarm (-55 ÷ 150°C) (-67÷ 302°F)
-40 Pr2
AU2 Condenser for high temperat. alarm (-55 ÷ 150°C) (-67÷ 302°F)
110 Pr2
AH2
Differ. for condenser temp. alar.
recovery
[0,1°C ÷ 25,5°C] [1°F ÷ 45°F]
5 Pr2
Ad2 Condenser temperature alarm delay 0 ÷ 254 (min.) , 255=nU
15 Pr2
dA2
Delay of cond. temper. alarm at start
up
0.0 ÷ 23h 50’
1,3 Pr2
bLL
Compr. off for condenser low
temperature alarm
n(0) - Y(1)
n Pr2
AC2
Compr. off for condenser high
temperature alarm
n(0) - Y(1)
n Pr2
AUXILIARY OUTPUT
tbA Alarm relay disabling n=no; y=yes
y Pr2
oA3 Fourth relay configuration ALr = alarm; dEF = do not select it;
Lig =Light; AUS =AUX; onF=always
on; Fan= do not select it; db = do
not select it; dF2 = do not select it
Lig Pr2
AoP Alarm relay polarity (oA3=ALr) oP; cL
cL Pr2
DIGITAL INPUT
i1P Digital input polarity oP=opening;CL=closing
cL Pr1
i1F Digital input configuration
EAL, bAL, PAL, dor; dEF; Htr, AUS
EAL Pr1
did Digital input alarm delay 0÷255min
5 Pr1
Nps Number of activation of pressure
switch
0 ÷15
15 Pr2
odc Compress and fan status when open
door
no; Fan; CPr; F_C
no Pr2
rrd Regulation restart with door open
alarm
n – Y
y Pr2
HES Differential for Energy Saving -30°C÷30°C; -54°F÷54°F
0 Pr2
OTHER
PbC Kind of probe
Ptc; ntc
1 Pr2
Adr Serrial address
1÷247
ntc Pr1
onF on/off key enabling nu, oFF; ES
oFF Pr2
dP3 Third probe display --
- Pr1
dP4 Fourth probe display --
- Pr1
rSE Current set point -
Pr1
rEL Software release - - -
1,1 Pr2
Ptb Map code - - -
- Pr2
dIXEL S.p.a.
Z.I. Via dell’Industria, 27 - 32010 Pieve d’Alpago (BL) ITALY
tel. +39 - 0437 - 98 33 - fax +39 - 0437 - 98 93 13
http://www.dixell.com
