1592009760 XW60VS GB Rel 1.1 .09.11.2011 XW60VS 4/4
13. DEFAULT SETTING VALUES
Label
Set Set point LS÷US
-5.0 ---
Hy Differential 0,1÷25,5 °C / 1÷45°F
2.0 Pr1
LS Minimum set point -50,0°C÷SET / -58°F÷SET
-30.0 Pr2
US Maximum set point SET ÷ 110°C / SET ÷ 230°F
20.0 Pr2
OdS Outputs activation delay at start up 0÷255 min.
0 Pr2
AC Anti-short cycle delay 0÷30 min.
1 Pr1
CCt Compressor ON time during fast freezing 0 ÷ 23h 50 min.
0.0 Pr2
COn Compressor ON time with faulty probe 0÷255 min.
15 Pr2
COF Compressor OFF time with faulty probe 0÷255 min.
30 Pr2
DISPLAY
CF Temperature measurement unit °C ÷ °F
°C Pr2
rES Resolution (integer/decimal point) in ÷ de
dE Pr1
Lod Local display P1 ÷ 1r2
P1 Pr2
DEFROST
tdF Defrost type rE, rT, in
rE Pr2
EdF Defrost mode In, Sd
in Pr2
SdF Set point for SMART DEFROST -30 ÷ +30°C / -22÷+86°F
0 Pr2
dtE Defrost termination temperature -50,0÷110°C/ -58÷230°F
8.0 Pr1
IdF Interval between defrost cycles 1÷120h
6 Pr1
MdF (Maximum) length for 1° defrost 0÷255 min.
30 Pr1
dFd Displaying during defrost rt, it, SEt, dEF, dEG
it Pr2
dAd MAX display delay after defrost 0÷255 min.
30 Pr2
dSd Delay before defrost 0÷255 min.
0 Pr2
Fdt Draining time 0÷60 min.
0 Pr2
dPO First defrost after start up n ÷ y
n Pr2
dAF Defrost delay after fast freezing 0 ÷ 23h 50 min.
0.0 Pr2
FANS
FnC Fans operating mode C-n, C-y, O-n, O-y
O-n Pr2
Fnd Fans delay after defrost 0÷255 min.
10 Pr2
FSt Fans stop temperature -50,0÷110°C/ -58÷230°F
2.0 Pr2
ALARMS
ALC Temperature alarms configuration rE÷Ab
Ab Pr2
ALU MAXIMUM temperature alarm -50,0÷110°C/ -58÷230°F
110 Pr1
ALL minimum temperature alarm -50,0÷110°C/ -58÷230°F
-40.0 Pr1
AFH Temperature alarm differential 0,1÷25,5 °C / 1÷45°F
2.0 Pr2
ALd Temperature alarm delay 0÷255 min.
15 Pr2
dAO Delay of temperature alarm at start up 0 ÷ 23h 50 min.
1.3 Pr2
EdA Alarm delay at the end of defrost 0÷255 min.
30 Pr2
dot Delay of temperature alarm after closing the door 0÷255 min.
15 Pr2
dOA Open door alarm delay 0÷255 min.
15 Pr2
nPS Pressure switch number 0÷15
0 Pr2
ANALOGUE INPUTS
Ot Thermostat probe calibration -12,0÷12,0°C / -21÷21°F
0 Pr1
OE Evaporator probe calibration -12,0÷12,0°C / -21÷21°F
0 Pr1
O3 Display probe calibration -12,0÷12,0°C / -21÷21°F
0 Pr1
P2P Evaporator probe presence n ÷ y
y Pr2
P3P Display probe presence n ÷ y
y Pr2
HES
Temperature increasing during the Energy Saving
cycle
-30÷30°F/-54÷54°F
0 Pr2
Odc Open door control no, Fan, CPr, F_C
FAn Pr2
I2P Configurable digital input polarity CL÷OP
cL Pr2
i2F Digital input configuration dor, EAL, bAL, PAL, dFr,
AUS, ES, OnF
dor Pr2
dId Digital input alarm delay 0÷255 min.
5 Pr2
Adr Serial address 0÷247
1 Pr2
Pbc Kind of probe PbC, ntc
ntc Pr2
rEL Software release - - - 2.0 Pr2
Ptb Map code - - - - - - Pr2
Prd Probes display Pb1÷Pb3 - - - Pr2
Pr2 Access parameter list - - - - - - Pr1
