Label
Name
Range
XLR130
XLR170
Level
HES
Temperature increase during the Energy Saving cycle
-30÷30°C / -54÷54°F
0
0
Pr2
DIGITAL INPUTS
Odc
Open door control
no, Fan, CPr, F_C
FAn
FAn
Pr2
I1P
Door switch polarity
CL÷OP
cL
cL
Pr2
I2P
Configurable digital input polarity
CL÷OP
cL
cL
Pr2
i2F
Digital input configuration
EAL, bAL, PAL,
dFr, AUS, ES, OnF
EAL
EAL
Pr2
dId
Digital input alarm delay
0÷255 min.
5
5
Pr2
oA1
Auxiliary relay configuration
dEF / ALr / FAn / LiG / AUS / onF / dF2 / cP2
AUS
AUS
Pr2
ACH
Kind of action for auxiliary relay
CL; Ht
cL
cL
Pr2
SAA
Set Point for auxiliary relay
-50,0÷110°C / -58÷230°F
0.0
0.0
Pr2
ArP
Probe selection for auxiliary relay
nP / P1 / P2 / P3
nP
nP
Pr2
oAP
Alarm relay polarity
oP; cL
cL
cL
Pr2
TIME AND WEEKLY HOLIDAYS
Hur
Current hour
0 ÷ 23
0
Pr2
Pr2
Min
Current minute
0 ÷ 59
0
Pr2
Pr2
dAY
Current day
Sun ÷ SAt
Sun
Pr2
Pr2
Hd1
First weekly holiday
Sun÷ SAt – nu
nu
Pr2
Pr2
Hd2
Second weekly holiday
Sun÷ SAt – nu
nu
Pr2
Pr2
Hd3
Third weekly holiday
Sun÷ SAt – nu
nu
Pr2
Pr2
ENERGY SAVING TIMES
ILE
Energy Saving cycle start during workdays
0 ÷ 23h 50 min.
0
Pr2
Pr2
dLE
Energy Saving cycle length during workdays
0 ÷ 24h 00 min.
0
Pr2
Pr2
ISE
Energy Saving cycle start on holidays
0 ÷ 23h 50 min.
0
Pr2
Pr2
dSE
Energy Saving cycle length on holidays
0 ÷ 24h 00 min.
0
Pr2
Pr2
HES
Temperature increase during the Energy Saving cycle
-30÷30°C / -54÷54°F
0
Pr2
Pr2
DEFROST TIMES
Ld1
1
st
workdays defrost start
0 ÷ 23h 50 min. - nu
6.0
6.0
Pr1
Ld2
2
nd
workdays defrost start
0 ÷ 23h 50 min. - nu
13.0
13.0
Pr1
Ld3
3
rd
workdays defrost start
0 ÷ 23h 50 min. - nu
21.0
21.0
Pr1
Ld4
4
th
workdays defrost start
0 ÷ 23h 50 min. - nu
0.0
0.0
Pr1
Ld5
5
th
workdays defrost start
0 ÷ 23h 50 min. - nu
0.0
0.0
Pr1
Ld6
6
th
workdays defrost start
0 ÷ 23h 50 min. - nu
0.0
0.0
Pr1
Ld7
7
th
workdays defrost start
0 ÷ 23h 50 min. - nu
0.0
0.0
Pr1
Ld8
8
th
workdays defrost start
0 ÷ 23h 50 min. - nu
0.0
0.0
Pr1
Sd1
1
st
holiday defrost start
0 ÷ 23h 50 min. - nu
6.0
6.0
Pr1
Sd2
2
nd
holiday defrost start
0 ÷ 23h 50 min. - nu
13.0
13.0
Pr1
Sd3
3
rd
holiday defrost start
0 ÷ 23h 50 min. - nu
21.0
21.0
Pr1
Sd4
4
th
holiday defrost start
0 ÷ 23h 50 min. - nu
0.0
0.0
Pr1
Sd5
5
th
holiday defrost start
0 ÷ 23h 50 min. - nu
0.0
0.0
Pr1
Sd6
6
th
holiday defrost start
0 ÷ 23h 50 min. - nu
0.0
0.0
Pr1
Sd7
7
th
holiday defrost start
0 ÷ 23h 50 min. - nu
0.0
0.0
Pr1
Sd8
8
th
holiday defrost start
0 ÷ 23h 50 min. - nu
0.0
0.0
Pr1
OTHER
Adr
Serial address
0÷247
1
1
Pr2
Pbc
Kind of probe selection
Pbc, ntc
ntc
ntc
Pr2
rEL
Software release
- - -
4.5
4.5
Pr1
Ptb
Map code
- - -
- - -
- - -
Pr1
dP1
First probe display
---
- - -
- - -
Pr1
dP2
Second probe display
---
- - -
- - -
Pr1
dP3
Third probe display
---
- - -
- - -
Pr1
Pr2
Access parameter list
- - -
- - -
- - -
Pr1
