Table 1 – Controller Board Connections
INDEX
NUMBER
CONNECTION DESCRIPTION
1 J18 Power from AC Distribution Box
2 J17 Bottle Drop Sensor
3 J15 Door Interlock Switch
4 J14 Coin Mechanism
5 J13 Digital Display
6 J12 Not Used
7 J11 Keypad
8 J10 Bill Validator
9 J9 Serial Port for Data Collection
10 TRAYS BOTTOM ROW
J3 –A, J4-B, J5 – C
TOP ROW
J6 – D, J7 – E, J8 – F
