Page 82
Service Door (Back)
INDEX
NUMBER
PART NUMBER PART DESCRIPTION
1 F557 Spacer, 10-32
2 F240-1 Latch Bar - 3 point lock
3 900,201,870.01 Phillips Trusshead Screw #10-32x3/8
4 F240-3 Latch Spacer, 3 point lock
5 900,701,160.01 Washer, Flat
6 900,701,220.01 Washer, Flat
7 900,202,030.01 Screw, Shoulder #10-32x1/4
8 801,518,050.01 Latch, Pawl - 3 point lock
9 F240-5 Latch Rod - 3 point lock
10 W199 Protective Strip, Plastic (2 pieces)
11 D588 Keypad Cable Clamp
D114 Keypad Cable Clamp Kit
12 803,853,660.01 Service Menu Label 2145 MM
W989-2 Service Card, 2054/2145, 220VAC
803,853,260.01 Service Menu Label DN2145, MDB
13 W396 Lanyard, Service Door
Part numbers subject to change without notice.
