Page 27 of 72
REAR SPACER
The Rear Spacer, one for each column, is located vertically at the rear of the column. The Springs,
adjustable by hand, slide into the holes in the column wall for cans and other package settings.
Rear Spacer Assembly
497,073,90x.x3 - Wide 600E
498,071,30x.x3 - Wide 501E
497,073,70x.x3 - Narrow 600E
498,071,40x.x3 - Narrow 501E/276E
FOR REFERENCE ONLY
Rear Spacer adjustment holes located in the sidewalls of the stacks.
