Set-up subject to change without notice. For packages not listed contact Dixie-Narco Factory
Service at (800) 688-9090. Page 34 of 72
CORRECTIONS FOR COMMON SINGLE PRICE VENDER
VENDING PROBLEMS
NOTE: When one or more circuits become inoperative on a Dixie-Narco vender, it is usually one
component that has failed, and it is with this in mind that the accompanying troubleshooting
schematic is presented.
Control Panel
Electrical Feed
Through Normally Closed of each Select Switch
1
Ï
2
Ï
3
Ï
4
Ï
5
Ï
6
Ï
7
Ï
8
Ï
9
Figure 1
Control Panel
(Select Button and Select Switch Location)
The control panel shown above represents a sample of the panels used on Dixie-Narco venders.
It is important to keep in mind the feed of electrical current through the select switches.
On the inside of the control panel, the select buttons and switches are numbered to assist identification. If
not numbered, then the select button arrangement is shown in the foregoing diagram.
Figure 1 represents a control panel on which the select buttons are arranged in a vertical pattern and the
power feed begins with the highest numbered switch and proceeds to the lowest numbered switch.
