Set-up subject to change without notice. For packages not listed contact Dixie-Narco Factory
Service at (800) 688-9090. Page 42 of 72
9. Problem: No motors work.
Troubleshooting: A) Check F2 motor power fuse (6 amp).
B) Check lamp and lamp wiring for broken, backed out, or crossed wires.
C) Check ballast and ballast wiring for broken, backed out, or crossed wires.
10. Problem: F2 Motor Power fuse continuously blows.
Troubleshooting: A) Check if 6 amp fuse is used.
B) Check that capacitor instead of MOV used at CR1 location.
C) Check ohms of each motor in off state
- unplug wires to coil of motor.
- ohms should be 6.5, if less coil of motor has a short.
D) Check motor harness.
E) Check motor extension harness.
F) Check for bad bulb in lighting system.
SIID COIN / CURRENCY
1. Problem: Will not accept coins or bills.
Troubleshooting: A) Check coin return lever is not pressed.
B) Check F3 peripheral (1.0 Amp) fuse.
C) Go to diagnostics and test.
1. Will not take coins, replace coin mech.
2. Still will not take coins, check connections and mech harness.
D) Check for bad connections or broken, backed out, or crossed wires from validator/changer to
control board.
E) With Mars 6510 Mdb mechs, serialized prior to 176xxxxxxxx that do not have a red dot on
the coin mech, check the coin mech.
F) Check control board.
2. Problem: Validator sometimes sets up credit and then steals bill.
Troubleshooting: A) Check for proper interface harness.
B) Check for bad connections or broken, backed out, or crossed wires from vend/sold-out
harness.
C) Check validator.
D) Check control board.
3. Problem: Accepts coins and displays, but will not vend.
Troubleshooting: A) Check coin mech.
B) Check for bad connections or broken, backed out, or crossed wires from validator/changer to
control board.
C) Check voltage supply (110-115AC) at outlet.
D) Check control board.
4. Problem: Incorrect change paid back, use correct change lamp stays on.
Troubleshooting: A) Check control board.
5. Problem: Cannot dump coins when in "Cd" mode or "CPO" mode.
Troubleshooting: A) Check for bad connections or broken, backed out, or crossed wires from changer to control
board.
B) Check select switches and wiring.
C) Check coin mech.
D) Ensure you are not using Mars International Executive or NRI Simplex changers.
E) Check voltage supply (110-115AC) at outlet.
F) Check control board.
6. Problem: BA30 stealing bills.
Troubleshooting: A) Check door switch.
B) Check validator.
