22
MACHINE SPECIFICATIONS
Weight of machine 28.3 kg (62.5 lbs)
MEK reservoir capacity 425 cc.
Mass of Rubbing Block 3kg (6.8 lbs) - Standard
Stroke Length 20.3cm (8”)
Number of strokes/min (Double Rub)* 70
Operational air pressure 550 KPa (80 psi)
Max air supply pressure 965 KPa (140 psi)
Air consumption @ operational pressure 66.54 L/min @ 345 KPa (50 psi)
Minimum Flexible air line supply size ¼” I.D.
Air inlet connection at filter ¼” NPT
Cotton Pad size 1½ x 1¾, 2 ply
Counter max number of strokes 99999
Air supply Clean and dry (non condensing)
Dimensions (Width Depth Height) 45.7cm x 48.3cm x 48.3mm (18” x 19” x 19”)
Test panel size 12.7cm x 30.5cm (5” x 12”)
Panel thickness max** 3.2 mm (1/8”)
Electrical Requirements None (all pneumatic system)
Compatible Solvents MEK, Acetyl Acetone, Acetone, Acetylene,
Isopropyl Alcohol, Methanol
* As per ASTM standard
** icker panels can be run, please contact DJH Designs for more information
Never use corrosive solutions. is machine is not designed to use anything other than
what is stated above under “compatible solvents”.
CAUTION
