dji Cendence User Manual

©
2017 DJI All Rights Reserved.
7
Preparing the Remote Controller
Mounting/Removing the Intelligent Battery
Put the battery into the Battery Slot, then slide it to the end until you hear a click.
Press the Battery Release Button before removing the battery.
Press the Battery Level Button once to check the battery level.
Charging the Battery
Theremote controllerispoweredbyaWB37 intelligent battery,whichcanbechargedvia the
charging port or by the WCH2 Intelligent Battery Charging Hub.
Using the Charging Port
The INSPIRE
TM
2 charger is used as for example below.
Place the battery into the remote controller, and connect connector B of the battery power port, then
connectthebatterychargertoapoweroutlet(100-240V,50/60Hz).Whenchargingiscomplete,the
display on the remote controller will show 100%.
OK
Charging Time: 2 hours and 24 min
Using the Charging Hub
The Inspire 2 Charger and the WCH2 Intelligent Battery Charging Hub are used for example below.
Place the battery into the Charging Hub, and connect connector B of the battery charger to the
charginghub, thenconnectthebatterycharger toapoweroutlet(100-240V, 50/60Hz).The
ChargingHubwillintelligentlychargebatteriesinsequenceaccordingtobatterypowerlevelsfrom
high to low. The buzzer will begin beeping when charging is complete. Remove the battery or turn
off the Buzzer Switch to stop it.
B
B
A
Power Qutlet
100~240 V
(50Hz/60Hz)
