dji GOGGLES INTEGRA MOTION COMBO User Manual

36
©
2023 DJI All Rights Reserved.
Appendix
Specifications
DJI Goggles Integra
Model Number RCDS13
Weight Approx. 410 g (battery included)
Dimensions
With antennas folded: 170×104×74.44 mm
With antennas unfolded: 205×104×104 mm
Screen Size (single screen) 0.49 in
Resolution (single screen) 1920×1080p
Refresh Rate Up to 100 Hz
IPD Range 56-72 mm
FOV (single screen) 44°
Transmission
When used with dierent aircraft, the goggles will automatically
select the corresponding rmware to match the transmission
specication of the aircraft.
Operating Frequency
2.4000-2.4835 GHz
5.725-5.850 GHz
[1]
Transmitter Power (EIRP)
2.4 GHz: <30 dBm (FCC), <20 dBm (CE/SRRC/MIC/KC)
5.8 GHz: <30 dBm (FCC), <23 dBm (SRRC), <14 dBm (CE/KC)
Transmission Latency
[2]
1080p@100fps: as low as 30 ms
1080p@60fps: as low as 40 ms
Max Video Bitrate
[3]
50 Mbps
Supported Video Recording Format MOV
Supported Video Playback Format
MP4, MOV
Video format: H.264, H.265
Audio format: AAC, PCM
Operating Temperature -10° to 40° C (14° to 104° F)
Supported SD Cards microSD Card, max 512 GB
Recommended microSD Cards
SanDisk Extreme
®
U3 V30 A1 32GB microSDXC™
SanDisk Extreme PRO U3 V30 A1 32GB microSDXC
Lexar
®
Professional 1066x U3 V30 A2 64GB microSDXC
Lexar Professional 1066x U3 V30 A2 128GB microSDXC
Lexar Professional 1066x U3 V30 A2 256GB microSDXC
Lexar Professional 1066x U3 V30 A2 512GB microSDXC
Kingston
®
Canvas Go! Plus U3 V30 A2 64GB microSDXC
Kingston Canvas Go! Plus U3 V30 A2 128GB microSDXC
Kingston Canvas React Plus U3 V90 A1 64GB microSDXC
Kingston Canvas React Plus U3 V90 A1 128GB microSDXC
Kingston Canvas React Plus U3 V90 A1 256GB microSDXC
Samsung
®
EVO Plus U3 V30 A2 512GB microSDXC
Integrated Battery Capacity 2450 mAh
Battery Voltage 5.6-8.4 V
Battery Type Li-ion
Battery Chemical System LiNiMnCoO2
Energy 17.64 Wh
