dji Goggles User Manual

Use the touch panel with your right hand to control on-screen operations.
Action
Description
Swipe forward/backward
with one finger
Browse the menu and scroll right/left
Swipe upward/downward
with one finger
Browse the menu and scroll up/down
In the Main view, swipe upward to hide warnings
Swipe backward with two
fingers
Lock the touch panel. It will become non-functional
Swipe forward with two
fingers
Unlock the touch panel
Swipe downward with two
fingers
Enter the shortcut menu
Swipe upward with two
fingers
Exit the shortcut menu
Tap with one finger
Confirm
[4] Charging Status Indicator
Indicates the current charging status, the LED be solid red, yellow, green to
reflect low, medium and high power levels respectively.

dji Goggles Specifications

Display

screen size	5 inch × 2
screen resolution	3840 × 1080 (single screen: 1920 × 1080)
live view modes	1080p30, 720p60, 720p30

Power

battery capacity	9440 mAh
charger input	100-240 VAC, 50 / 60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2 A / 12 V 1.5 A

Operating Environment

operating temperature range	32° to 104° F (0° to 40° C)
communication frequency	2.4 GHz

Weight and Dimensions

weight (DJI Goggles Body)	495 g
weight (Headband)	500 g
dimensions (DJI Goggles Body)	195 × 155 × 110 mm
dimensions (Headband folded)	255 × 205 × 92 mm
