dji Goggles User Manual

4. Choose “Normal” and confirm. The Goggles’ linking status indicator will go
solid red to wait for linking.
5. Press the Linking Button on the Mavic Pro. Once linked, the Goggles’ linking
status indicator will turn solid green.
 Toggle the control mode switch of the Remote Controller to RC mode
before linking.
Other DJI Aircraft
Goggles also supports other DJI aircraft. Connect Goggles to the either the Micro
USB port or the HDMI port of the Remote Controller.
Main Screen
The main screen of Goggles and functions are described as follows:

dji Goggles Specifications

Display

screen size	5 inch × 2
screen resolution	3840 × 1080 (single screen: 1920 × 1080)
live view modes	1080p30, 720p60, 720p30

Power

battery capacity	9440 mAh
charger input	100-240 VAC, 50 / 60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2 A / 12 V 1.5 A

Operating Environment

operating temperature range	32° to 104° F (0° to 40° C)
communication frequency	2.4 GHz

Weight and Dimensions

weight (DJI Goggles Body)	495 g
weight (Headband)	500 g
dimensions (DJI Goggles Body)	195 × 155 × 110 mm
dimensions (Headband folded)	255 × 205 × 92 mm
