dji Inspire 1 User Manual

©
2016 DJI. All Rights Reserved.
11
User Manual
INSPIRE RAW
Preparing Remote Controller
Tilt the Mobile Device Holder to the desired position then adjust the antenna as shown.
1. Press the button on the side of the Mobile Device Holder to release the clamp, adjust it to t then attach
your mobile device.
2. Connect your mobile device to the remote controller with a USB cable.
3. Plug one end of the cable into your mobile device, and the other end into the USB port on the back of
the remote controller.
Attaching 1345T Quick-Release Propellers
Following the steps below to attach the 1345T Quick-Release propellers.
1. Pair the propellers and motors with arrows of the same color (red or white).
3
1
2
Propeller Lock
Rotate the propeller lock until
the arrows are aligned and you
hear a click.
Attach the propeller onto
the motor.
Once again, rotate the propeller
lock until you hear a click.

dji Inspire 1 Specifications

General

Product color	Black, White
Frequency band	2.4 - 2.483 GHz
Number of rotors	4 rotors
Channels quantity	3 channels
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Megapixel	12.4 MP
Video resolutions	1280 x 720, 1920 x 1080, 4096 x 2160 pixels
Maximum frame rate	60 fps
Supported video modes	720p, 1280p, 2160p
Maximum video resolution	4096 x 2160 pixels
Compatible memory cards	MicroSD (TransFlash)
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
Battery voltage	22.2 V
Battery capacity	4500 mAh

Weight and Dimensions

Depth	451 mm
Width	438 mm
Height	301 mm
Weight	2935 g
