dji M200 Series User Manual

Installation and Usage (cont…)
To power the unit on, please move the switch towards the
right position. The green LED will illuminate confirming the
unit is powered on. If installed correctly and without any
technical faults, the unit will automatically close the pin.
The drop system relies on the navigation light of your aircraft,
which is located just below the motor, to
know when to engage. When the
navigation light is on, the drop system
will engage, dropping the payload.
As long as the navigation light remains
off, the drop system will keep the pin
closed, preventing the payload from
dropping. The navigation light can be
controlled directly from the DJI Pilot or
DJI Go 4 application on your phone,
tablet, or CrystalSky.
10
When the drop system is in
the engaged/open position,
the red LED will illuminate.
INJURY RISK!
DO NOT PLACE YOUR
FINGERS OR ANY FOREIGN
OBJECTS IN THE PAYLOAD
PIN CAVITY THAT DO NOT
BELONG!

dji M200 Series Specifications

General

Satellite Positioning Systems	GPS, GLONASS
IP Rating	IP43
Supported Gimbal	Zenmuse X4S, Zenmuse X5S, Zenmuse Z30
Operating Temperature	-20°C to 50°C
Weight	4.2 kg (with battery and propellers)
Max Ascent Speed	5 m/s (S-mode)
Max Descent Speed	3 m/s (S-mode), 3 m/s (P-mode)
Max Speed	44.7 mph / 20 m/s
Max Flight Time	38 minutes
Max Hovering Time	32 minutes (with TB55 battery)
Max Flight Distance	7 km
Operating Temperature Range	-20°C to 50°C
Hovering Accuracy Range	0.5 m
