dji M200 Series User Manual

Installation and Usage
To ensure that your Drop System functions correctly, we
recommend following the installation and usage guidelines
detailed below. Should a part or component not function as
explained, please contact DJI Shop Canada for support.
Step 1
Remove the landing gear from your aircraft.
Step 2
Remove the three screws securing the landing gear bracket.
5

dji M200 Series Specifications

General

Satellite Positioning Systems	GPS, GLONASS
IP Rating	IP43
Supported Gimbal	Zenmuse X4S, Zenmuse X5S, Zenmuse Z30
Operating Temperature	-20°C to 50°C
Weight	4.2 kg (with battery and propellers)
Max Ascent Speed	5 m/s (S-mode)
Max Descent Speed	3 m/s (S-mode), 3 m/s (P-mode)
Max Speed	44.7 mph / 20 m/s
Max Flight Time	38 minutes
Max Hovering Time	32 minutes (with TB55 battery)
Max Flight Distance	7 km
Operating Temperature Range	-20°C to 50°C
Hovering Accuracy Range	0.5 m
