dji M200 Series User Manual

Parts and Components (cont…)
In the Box
4
11
Rear
8. Navigation Light Cover
9. Light Sensor Wire Routing Clip (Arm)
10. Light Sensor Wire Routing Clip (Bracket)
11. Manual Pin Release Button
1x Drop System Assembly
1x Electronics Bay Cover
1x Navigation Light Cover
4x Light Sensor Wire
Routing Clips (2 Arm, 2
Bracket)
1x Li-Po Battery
1x Battery USB Charger
2x Carabiner Clips
6x Button/Socket Head Screws
+ 1 spare
8
9
10

dji M200 Series Specifications

General

Satellite Positioning Systems	GPS, GLONASS
IP Rating	IP43
Supported Gimbal	Zenmuse X4S, Zenmuse X5S, Zenmuse Z30
Operating Temperature	-20°C to 50°C
Weight	4.2 kg (with battery and propellers)
Max Ascent Speed	5 m/s (S-mode)
Max Descent Speed	3 m/s (S-mode), 3 m/s (P-mode)
Max Speed	44.7 mph / 20 m/s
Max Flight Time	38 minutes
Max Hovering Time	32 minutes (with TB55 battery)
Max Flight Distance	7 km
Operating Temperature Range	-20°C to 50°C
Hovering Accuracy Range	0.5 m
