Attaching a Payload (cont…)
With the payload pin open, insert the included carabiner clip
into the cavity underneath the drop system where the payload
pin is. Once the clip is inserted, you may release the manual
pin release button to close the payload pin. At this point, you
may connect your payload to the carabiner clip.
When attaching a payload, you must keep at least 1m/~3ft of
clearance between the belly of the aircraft and the top of your
payload. If this distance is shortened, your aircrafts downward
vision system may detect an object that is too close and will
attempt to hover upward which can lead to a crash.
12
It is important to ensure that the payload
remains at least 1m/~3ft away from the
aircraft when connected.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji M200 Series and is the answer not in the manual?

dji M200 Series Specifications

General IconGeneral
Satellite Positioning SystemsGPS, GLONASS
IP RatingIP43
Supported GimbalZenmuse X4S, Zenmuse X5S, Zenmuse Z30
Operating Temperature-20°C to 50°C
Weight4.2 kg (with battery and propellers)
Max Ascent Speed5 m/s (S-mode)
Max Descent Speed3 m/s (S-mode), 3 m/s (P-mode)
Max Speed44.7 mph / 20 m/s
Max Flight Time38 minutes
Max Hovering Time32 minutes (with TB55 battery)
Max Flight Distance7 km
Operating Temperature Range-20°C to 50°C
Hovering Accuracy Range0.5 m
