A Slave remote controller cannot link to the aircraft and so therefore cannot control the
orientation of the aircraft. Select Master in DJI GO 4 if you wish to link a remote controller
it to the aircraft.
A remote controller will disconnect from the linked aircraft if a new remote controller is
linked to the same aircraft.
Press the C1 and C2 buttons and the Start/Stop button for fast linking.
4. The remote controller is ready to link. The Remote Controller Status Indicator blinks blue, and a
“beep” sound is emitted.
5. Locate the Linking button on the aircraft, as shown in the gure shown below. Press the Linking
button to start linking. The Remote Controller Status Indicator will display solid green if the con-
nection is successful.
