Appendix
Specications
Aircraft
Model M200
Dimensions
Unfolded, 887×880×378 mm
Folded, 716×220×236 mm
Diagonal Wheelbase 643 mm
Max Takeoff Weight 6.14 kg
Max Payload
2.34 kg (with two standard batteries ),
1.61 kg (with two optional batteries)
Hovering Accuracy (P-mode with GPS)
Vertical: ±1.64 feet (0.5 m) or ±0.33 feet (0.1 m,
Downward Vision System enabled)
Horizontal: ±4.92 feet (1.5 m) or ±0.98 feet (0.3 m,
Downward Vision System enabled)
Max Angular Velocity Pitch: 300°/s, Yaw: 150°/s
Max Pitch Angle
35° (In P-mode and Forward Vision System enabled:
25°)
Max Ascent Speed 16.4 ft/s (5 m/s)
Max Descent Speed (Vertical) 9.8 ft/s (3 m/s)
Max Speed
P-mode: 61 kph(17 m/s); S-mode/A-mode: 83 kph (23
m/s)
Max Service Ceiling Above Sea Level 3000 m
Max Wind Resistance 32.8 ft/s (10 m/s)
Max Flight Time (with standard batteries) 27 min (No payload), 13 min (Takeoff weight: 6.14 kg)
Max Flight Time (with optional batteries) 38 (No payload), 24 min (Takeoff weight: 6.14 kg)
Motor Model DJI 3515
Propeller Model 1760S
Supported DJI Gimbals Zenmuse X4S/X5S/XT/Z30
Supported Gimbal Mounting Single Downward Gimbal
Waterproof Level IP43
GNSS GPS+GLONASS
Operating Temperature -4° to 113° F (-20° to 45° C)
Gimbal
Angular Vibration Range ±0.01°
Controllable Range Pitch: -130° to +40°; Roll: ±20°; Pan: ±320°
Max Controllable Speed Pitch: 180°/s; Roll:180°/s; Pan:270°/s
Interface Type DGC2.0
Mechanical Range Pitch: -140° to +50°; Roll: -50° to +90°; Pan: ±330°
