MATRICE 200 User Manual
Detection Range
The detection range of the Vision System is depicted below. Note that the aircraft cannot sense
and avoid obstacles that are not within the detection range.
40cm
60cm
Vision System and Infrared Sensing System
The main components of the Vision System are located on the front and bottom of the aircraft, in-
cluding [1] [3] stereo vision sensors and [2] two ultrasonic sensors. The Vision Sys tem uses ultra-
sound and image data to help the aircraft maintain its current position, enabling precision hovering
indoors or in environments where a GPS signal is not available. The Vision System constantly scans
for obstacles, allowing the Matrice 200 to avoid them by going over, going around, or hovering.
The Infrared Sensing System consists [4] of two infrared modules on top of the aircraft. These scan
for obstacles on top side of the aircraft and is active in certain ight modes.
The aircraft cannot detect objects in low-light conditions. Please y with caution.
[2]
[4]
[3]
[1]
