DJI Osmo Action 3

User Manual

The transmitter and the receiver are linked by default. Follow the steps below to link if

the transmitter and receiver are disconnected.

• Place the transmitter and the receiver in the charging case to link automatically.

• Power on the transmitter and the receiver, press and hold the link button on the

transmitter, slide down on the screen of the receiver, select Settings and scroll through

and tap Link Device to start linking. The status LED glows solid green to indicate linking

was successful.

REC

Follow the steps below (with DJI Mic as an example) to connect to a microphone:

1. Press the release button on the USB-C port cover and slide it downward. Lift the cover

upward until it is detached from the device.

2. Power on the receiver and transmitters, and make sure the receiver and transmitters

are linked.

3. Attach the receiver to the USB-C port of the camera using the USB-C adapter. A

microphone icon will be displayed on the screen.

4. Press the linking button on the transmitter to start recording while using the

transmitter for audio.

Other manuals for dji OSMO ACTION 3

Questions and Answers:

Need help?

Do you have a question about the dji OSMO ACTION 3 and is the answer not in the manual?

General

Slow motion	4, 8 x
Aspect ratio	4:3, 16:9
Time lapse mode	Yes
Maximum frame rate	240 fps
Supported video modes	1080p, 1512p, 2160p
Video formats supported	H.264, HEVC, MP4
Maximum video resolution	4096 x 3072 pixels
Battery type	Built-in
Battery voltage	3.85 V
Battery capacity	1770 mAh
Battery life (max)	2.6 h
Sensor type	CMOS
Total megapixels	12 MP
Optical sensor size	1/1.7 \
Image formats supported	JPEG, RAW
Maximum image resolution	4000 x 3000 pixels
Operating temperature (T-T)	-20 - 45 °C
Flip-out screen	No
Display diagonal	2.25 \
Display resolution	360 x 640 pixels
Digital zoom	4 x
Image stabilizer type	Electronic Image Stabilization (EIS)
Field of view (FOV) angle	155 °
ISO sensitivity	100, 12800
Audio recording formats	AAC
Underwater case waterproof up to	60 m
Storage media	Memory card
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
GPS (satellite)	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Product color	Black
Waterproof up to	16 m
