2015 DJI. All Rights Reserved.
29
Remote Controller
Phantom 3 Advanced
User Manual
The remote controller will un-link itself from an aircraft if a new remote controller is linked to the
same aircraft.
Remote Controller Compliance Version
The remote controller is compliant with both CE and FCC requirements.
Link Button
RC Control Setting
RC Calibration
Stick Mode
Not DefinedC1 C2 Not Defined
Default stick mode is Mode 2, changing stick modes alters the way the aircraft is controlled.
Do not change unless familiar with your new mode.
You can customize the C1 and C2 buttons on the back
of the RC.
Linking RC
Searching for aircraft frequency,
timeout in 54 seconds
Cancel
Press the linking button on the aircraft
to link this remote controller
5. Locate the linking button on the side of the aircraft, as shown in the gure below. Press the link button
to start linking. The Remote Controller Status Indicator LED will display a solid green once the remote
controller is successfully linked to the aircraft.
4. The remote controller is ready to link. The Remote Controller Status Indicator blinks blue and a beep is
emitted.
