Gimbal Camera

Camera and Gimbal

CameraProle

The on-board camera uses a 1/2.3 inch CMOS sensor to capture video (up to1080p at 60 frames per

second with the Phantom 3 Advanced) and 12 megapixel stills. You may choose to record the video in

either MOV or MP4 format. Available picture shooting modes include burst, continuous, and time-lapse

mode. A live preview of what the camera sees can be monitored on the connected mobile device via the

DJI Pilot app.

Camera Micro-SD Card Slot

To store your photos and videos, insert the Micro-SD card into the slot, as shown below, before

turning on the Phantom 3 Advanced. The Phantom 3 Advanced comes with a 16 GB Micro-SD card

and supports Micro-SD cards up to 64 GB. A UHS-1 Micro-SD card is recommended due to their

fast read and write speeds allowing you to save high-resolution video data.

Do not remove the Micro-SD card from the Phantom 3 Advanced when it is turned on.

Camera Data Port

Turn on the Phantom 3 Advanced and connect a USB cable to the Camera Data Port to download photos

and videos to your computer.

The aircraft must be turned on before attempting to access the les on the Micro-SD card.

Other manuals for dji Phantom 3 Advanced

Questions and Answers:

Need help?

Do you have a question about the dji Phantom 3 Advanced and is the answer not in the manual?

General

Maximum speed	16 m/s
Frequency band	2.4 - 2.483 GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum flight time	23 min
Maximum ascent speed	5 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Megapixel	12.4 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520 pixels
Maximum frame rate	60 fps
Camera shutter speed	8 - 1/8000 s
Supported video modes	720p, 1080p, 1520p
Video formats supported	AVC, H.264, MOV, MP4, MPEG4
Live view frequency band	2.4 GHz
Maximum video resolution	2704 x 1520 pixels
Field of view (FOV) angle	94 °
Bitrate at maximum video resolution	40 Mbit/s
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Flight modes	Failsafe mode, Follow Me mode
Moving control functions	Backward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Battery voltage	15.2 V
Battery capacity	4480 mAh
Transmitter battery capacity	6000 mAh
Number of batteries (transmitter)	1
Product color	White
Operating temperature (T-T)	0 - 40 °C
AC adapter power	57 W
AC adapter output voltage	17.4 V
Equivalent Isotropically Radiated Power (EIRP)	100 dBmW
Motor type	Brushless
