DJI Pilot App

Phantom 3 Advanced

User Manual

[1] Flight Mode

: The text next to this icon indicates the current ight mode.

Tap to congure the MC (Main Controller) Settings. These settings allow you to modify ight limits and

set the gain values.

[2] GPS Signal Strength

: This icon shows the current strength of GPS signals. Green bars indicate adequate GPS

strength.

[3] IOC Settings

: This icon displays the IOC setting when the aircraft has entered F-mode. Tap to view the IOC

settings menu and select the desired IOC setting.

[4] System Status

: This icon indicates the current aircraft system status and GPS signal strength.

[5] Battery Level Indicator

: The battery level indicator provides a dynamic display of the battery level. The colored

zones on the battery level indicator represent the power levels needed to carry out different functions.

[6] Remote Controller Signal

: This icon shows the strength of remote controller’s signal.

[7] HD Video Link Signal Strength

This icon shows the strength of the HD video downlink connection between the aircraft and

the remote controller.

[8] Battery Level

: This icon shows the current battery level.

Tap to view the battery information menu, set the various battery warning thresholds, and view the

battery warning history.

[9] General Settings

: Tap this icon to view the General Settings page. From this page, you can set ight parameters,

reset the camera, enable the quick view feature, adjust the gimbal roll value, and toggle the ight

route display.

[10] Camera Operation Bar

Shutter and Recording Settings

: Tap to enter various camera value settings, including color space for the recording, resolution of

the videos, image size and so on.

Shutter

: Tap this button to take a single photo. Press and hold this button to select single shot, triple shot

or time-lapsed shooting modes.
