2015 DJI. All Rights Reserved.
51
FAQ
Phantom 3 Advanced
User Manual
What is the Phantom 3 ight time?
Flight times will vary depending on environmental conditions and usage patterns, but the Intelligent Flight
Battery is designed to provide up to 23 minutes of uninterrupted ight time when fully charged.
How can I restore a video le if the power is turned off during recording?
Do not remove the Micro-SD card from the camera. If it has been removed, place it back in the camera.
Turn the Phantom 3 on and wait approximately 30 seconds as the video le is restored.
How can I ensure that my pictures and videos will be synchronized to my iOS album?
You may need to adjust the settings of your mobile device. Open the Settings menu, select the Privacy
tab, select the Photos tab, and then toggle the switch next to the DJI Pilot app icon. If the Pilot app has not
been granted access to your albums, the photos and videos cannot be synchronized.
What should I do to land my Phantom 3 smoothly as possible?
Hover the aircraft over a at, level surface. Slowly pull the throttle stick down until the aircraft touches the
ground.
Why is the discharge time of the battery not zero, even though I have never used it?
Every battery is tested prior to being packaged and shipped. This affects the discharge time of a new
battery and is the reason that the discharge time is not zero. The battery is safe to use.
Can the mobile device holder be used on the Phantom 2 series Remote Controller?
No, it cannot.
How to safely operate the aircraft when encountering compass error?
A compass error may occur when the aircraft is ying close to strong electric magnetic sources (e.g.
power transmission lines). Aircraft Status Indicators blink red and yellow rapidly when a compass error
occurs and the DJI Pilot app will display one of the following messages:
• Compass error, calibration required
This warning message indicates the aircraft is receiving abnormal compass readings. It is recommended
to power off the aircraft and re-calibrate the compass at a different location and then resume the ight.
• Compass error, exit P-GPS Mode
This warning message indicates that the aircraft is drifting severely. Bring the aircraft to a higher altitude
to gain enough GPS satellite locks when this warning message is prompted. The flight controller will
automatically adjust the orientation of the aircraft in the midair to mitigate the drifts. The aircraft will switch
back to P-GPS mode when the automatic adjustment is completed.

Other manuals for dji Phantom 3 Advanced

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji Phantom 3 Advanced and is the answer not in the manual?

dji Phantom 3 Advanced Specifications

General IconGeneral
Maximum speed16 m/s
Frequency band2.4 - 2.483 GHz
Number of axis3
GPS (satellite)Yes
Number of rotors4 rotors
Maximum flight time23 min
Maximum ascent speed5 m/s
Maximum descent speed3 m/s
Maximum weight capacity- kg
Maximum operating distance5000 m
Megapixel12.4 MP
Video resolutions1280 x 720, 1920 x 1080, 2704 x 1520 pixels
Maximum frame rate60 fps
Camera shutter speed8 - 1/8000 s
Supported video modes720p, 1080p, 1520p
Video formats supportedAVC, H.264, MOV, MP4, MPEG4
Live view frequency band2.4 GHz
Maximum video resolution2704 x 1520 pixels
Field of view (FOV) angle94 °
Bitrate at maximum video resolution40 Mbit/s
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size64 GB
Flight modesFailsafe mode, Follow Me mode
Moving control functionsBackward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Battery voltage15.2 V
Battery capacity4480 mAh
Transmitter battery capacity6000 mAh
Number of batteries (transmitter)1
Product colorWhite
Operating temperature (T-T)0 - 40 °C
AC adapter power57 W
AC adapter output voltage17.4 V
Equivalent Isotropically Radiated Power (EIRP)100 dBmW
Motor typeBrushless
Weight and Dimensions IconWeight and Dimensions
Weight1280 g
Battery weight365 g
