Phantom4 UserManual
Aircraft
Battery Level Indicators while Charging
LED1 LED2 LED3 LED4 Battery Level
0%~25%
25%~50%
50%~75%
75%~100%
Fully Charged
Charging Protection LED Display
The table below shows battery protection mechanisms and corresponding LED patterns.
Battery Level Indicators while Charging
LED1 LED2 LED3 LED4 Blinking Pattern Battery Protection Item
LED2 blinks twice per second
Over current detected
LED2 blinks three times per second Short circuit detected
LED3 blinks twice per second
Over charge detected
LED3 blinks three times per second
Over-voltage charger detected
LED4 blinks twice per second
Room temperature is not suitable
for charging
LED4 blinks three times per second
Room temperature is not suitable
for charging
After any of the above mentioned protection issues are resolved, press the button to turn off the Battery Level
Indicator. Unplug the Intelligent Flight Battery from the charger and plug it back in to resume charg- ing.
Note that you do not need to unplug and plug the charger in the event of a room temperature error, the charger will
resume charging when the temperature falls within the normal range.
DJI does not take any responsibility for damage caused by third-party chargers.
How to discharge your Intelligent Flight Battery:
Slow : Place the Intelligent Flight Battery into the The Phantom 4’s Battery Compartment and
power it on. Leave it on until there is less than 8% of power left, or until the battery can no longer be
turned on. Launch the DJI Pilot app to check battery levels.
Rapid : Fly the The Phantom 4 outdoors until there is less than 8% of power left, or until
the battery can no longer be turned on.
