Phantom4 UserManual
28
©
2015 DJI. All Rights Reserved.
Remote
Controllers
Status LED Alarm Remote Controller Status
The remote controller set as "Master" but it is not
—
Solid Red None
—
Solid Green None
—
Solid Purple None
—
Solid Blue None
connected with the aircraft.
The remote controller set as "Master" and it is connected with the
aircraft.
The remote controller set as "Slave" but it is not
connected with the aircraft.
The remote controller set as "Slave" and it is connected with the
aircraft.
Slow Blinking Red B-B-B…… Remote controller error.
/
Red and Green/ Red and
Yellow Alternate Blinks
None HD Downlinkd is disruptted.
RTH LED Sound Remote Controller Status
B…… Sending Return to Home command to the aircraft.
Blinking White
BB…… Aircraft Return to Home in progress.
—
Solid White BBB--BB Aircraft is returning home.
The Remote Status Indicator will blink red, sound an alert, when the battery level is critically low.
Linking the Remote Controller
The remote controller is linked to your aircraft before delivery. Linking is only required when using a new
remote controller for the first time. Follow these steps to link a new remote controller:
1. Power on the remote controller and connect to the mobile device. Launch DJI Pilot app.
2. Power on the Intelligent Flight Battery.
3. Enter “Camera” view and tap on and then tap “Linking Remote Controller” . Follow the prompt
instruction to proceed.
4. Locate the Linking button on the front of the aircraft, as shown in the figure shown below.
Linking Button
