dji PHANTOM 4 User Manual

6
©
2015 DJI. All Rights Reserved.

Product
Profile
Product Profile

Introduction

The Phantom 4 is a brand new quadcopter capable of capturing HD video and transmitting an HD video
signal out of the box. The built-in camera has an integrated gimbal to maximize stability and
weight
efficiency while minimizing space. When no GPS signal is available, Vision Positioning technology provides
hovering precision.

Feature Highlights

Camera and Gimbal: Up to 4K video*(Phantom 4) recording and 12 megapixel photo capture. Re-
served mounting space for ND filters for better exposure control.

HD Video Downlink: Low latency, HD downlink powered by an enhanced version of the DJI Lightbridge system.
It also provides dual controllers mode.

DJI Intelligent Flight Battery: 5350 mAh DJI Intelligent Flight Battery employs new battery cells and a bat-
tery management system.

Flight Controller: The next generation flight controller system provides a more reliable flight experience. A new
flight recorder stores the flight data from each flight, and Vision Positioning enhances hovering preci- sion when
flying indoors and no GPS is available.

dji PHANTOM 4 Specifications

General

Product color	White
Frequency band	2.4 - 2.483 GHz
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Number of propeller blades	2
Moving control functions	Downward, Forward, Turn left, Turn right, Upward
Cables included	USB
Memory card included	MicroSD
Megapixel	12 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Maximum video resolution	4096 x 2160 pixels
Compatible memory cards	MicroSD (TransFlash)
Battery voltage	7.4 V
Battery capacity	6000 mAh

Weight and Dimensions

Width	289.5 mm
Height	196 mm
Weight	1380 g
