dji PHANTOM 4 User Manual

©
2015 DJI. All Rights Reserved.
53


Appendix

Max Bitrate Of Video
Storage

60 Mbps

Supported File
Formats


Supported SD Card
Types

Remote Controller
FAT32/exFAT
Photo: JPEG, DNG
Video: MP4/MOV (MPEG-4 AVC/
H.264)
Micro SD
Max capacity: 64 GB. Class 10 or
UHS-1 rating required.
Operating Frequency 2.400 GHz-2.483 GHz
Transmitting Distance Up to 5 km (unobstructed, free of interference) when FCC compliant
Up to 3.5 km (unobstructed, free of interference) when CE compliant
Video Output Port USB
Operating
Temperature
0°- 40°
Battery 6000 mAh LiPo 2S
Mobile Device Holder tablet and phone
Power 1.2 A @7.4 V
Charger
Voltage 17.5 V
Rated Power 100 W
Intelligent Flight Battery ( PH3-5350 mAh-15.2 V )

Capacity 5350 mAh
Voltage 15.2 V
Battery Type LiPo 4S
Energy 68 Wh
Net Weight
365 g
Operating
Temperature

-10°- 40°
Max Charging Power 100 W

dji PHANTOM 4 Specifications

General

Product color	White
Frequency band	2.4 - 2.483 GHz
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Number of propeller blades	2
Moving control functions	Downward, Forward, Turn left, Turn right, Upward
Cables included	USB
Memory card included	MicroSD
Megapixel	12 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Maximum video resolution	4096 x 2160 pixels
Compatible memory cards	MicroSD (TransFlash)
Battery voltage	7.4 V
Battery capacity	6000 mAh

Weight and Dimensions

Width	289.5 mm
Height	196 mm
Weight	1380 g
