DJI RC User Manual
10
©
2022 DJI All Rights Reserved.
Stick Neutral/Center Point: Control sticks are in the center.
Moving the control stick: The control stick is pushed away from the center position.
The gure below explains how to use each control stick. Mode 2 has been used as an example.
Remote Controller
(Mode 2)
Aircraft Remarks
Left Stick
UP
Down
Moving the left stick up or down changes the
aircraft’s altitude. Push the stick up to ascend and
down to descend. The more the stick is pushed
away from the center position, the faster the
aircraft will change altitude. Push the stick gently
to prevent sudden and unexpected changes in
altitude.
Left Stick
Turn RightTurn Left
Moving the left stick to the left or right controls
the orientation of the aircraft. Push the stick left to
rotate the aircraft counter-clockwise and right to
rotate the aircraft clockwise. The more the stick is
pushed away from the center position, the faster
the aircraft will rotate.
Right Stick
Forward
Backward
Moving the right stick up and down changes the
aircraft’s pitch. Push the stick up to y forward
and down to y backward. The more the stick is
pushed away from the center position, the faster
the aircraft will move.
Right Stick
RightLeft
Moving the right stick to the left or right changes
the aircraft’s roll. Push the stick left to y left and
right to y right. The more the stick is pushed
away from the center position, the faster the
aircraft will move.
Keep the remote controller away from magnetic materials to avoid it being aected by magnetic
interference.
To avoid damage, it is recommended that the control sticks are removed and stored in the storage
slot on the remote controller during transportation or storage.
Flight Mode Switch
Toggle the switch to select the desired ight mode.
Position Flight Mode
C Cine Mode
N Normal Mode
S Sport Mode
CNS
