dji RC User Manual

DJI RC User Manual
7
©
2022 DJI All Rights Reserved.
Activating the Remote Controller
Internet
The remote controller needs to be activated before using for the rst time. Make sure the
remote controller can connect to the internet during activation. Follow the steps below to
activate the remote controller.
1. Power on the remote controller. Select the language and tap “Next”. Carefully read the terms of use
and privacy policy and tap “Agree”. After conrming, set the country/region.
2. Connect the remote controller to the internet via Wi-Fi. After connecting, tap “Next” to continue and
select the time zone, date, and time.
3. Log in with your DJI account. If you do not have an account, create a DJI account and log in.
4. Tap “Activate” on the activation page.
5. After activating, select if you would like to join the improvement project. The project helps to improve
the user experience by sending diagnostic and usage data automatically every day. No personal data
will be collected by DJI.
Check the internet connection if the activation fails. If the internet connection is normal, please try to
activate the remote controller again. Contact DJI Support if the issue persists.

dji RC Specifications

General

Wi-Fi	Yes
Proper use	Universal
Product type	Remote control
Compatibility	DJI Mini 3 Pro DJI Mavic 3 DJI Mavic 3 Cine
Frequency band	2.400-2.4835; 5.725-5.850 GHz
Bluetooth version	4.2
Brand compatibility	DJI
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Maximum operating distance	15000 m
Equivalent Isotropically Radiated Power (EIRP)	26 dBmW
Display diagonal	5.5 \
Display brightness	700 cd/m²
Battery voltage	3.6 V
Battery capacity	5200 mAh
Battery life (max)	4 h
Battery recharge time	1.5 h
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	168.4 mm
Width	123.7 mm
Height	62.7 mm
Weight	390 g
