dji RC User Manual

DJI RC User Manual
16
©
2022 DJI All Rights Reserved.
Quick Settings
2
3
4
5
1
1. Notications
Tap to check system notications.
2. System Settings
Tap to access system settings and congure the Bluetooth, volume, network, etc. You can also
view the Guide to learn more about the controls and status LEDs.
3. Shortcuts
: Tap to enable or disable Wi-Fi. Hold to enter settings and then connect to or add a Wi-Fi
network.
: Tap to enable or disable Bluetooth. Hold to enter settings and connect with nearby Bluetooth
devices.
: Tap to enable Airplane mode. Wi-Fi and Bluetooth will be disabled.
: Tap to turn o system notications and disable all alerts.
: Tap to start recording the screen*. The function will be available only after a microSD card is
inserted into the microSD slot on the remote controller.
: Tap to take a screenshot. The function will be available only after a microSD card is inserted into
the microSD slot on the remote controller.
4. Adjusting Brightness
Slide the bar to adjust the screen brightness.
5. Adjusting Volume
Slide the bar to adjust the volume.
* When the remote controller is linked with DJI Mavic 3, the frame rate of the transmission image will drop to
30fps during the recording.

dji RC Specifications

General

Wi-Fi	Yes
Proper use	Universal
Product type	Remote control
Compatibility	DJI Mini 3 Pro DJI Mavic 3 DJI Mavic 3 Cine
Frequency band	2.400-2.4835; 5.725-5.850 GHz
Bluetooth version	4.2
Brand compatibility	DJI
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Maximum operating distance	15000 m
Equivalent Isotropically Radiated Power (EIRP)	26 dBmW
Display diagonal	5.5 \
Display brightness	700 cd/m²
Battery voltage	3.6 V
Battery capacity	5200 mAh
Battery life (max)	4 h
Battery recharge time	1.5 h
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	168.4 mm
Width	123.7 mm
Height	62.7 mm
Weight	390 g
