Controlling the Aircraft
The control sticks control the aircraft’s orientation (pan), forward/backward movement (pitch), altitude
(throttle), and left/right movement (roll). The control stick mode determines the function of each control
stick movement. Three preprogrammed modes (Mode 1, Mode 2, and Mode 3) are available and
custom modes can be congured in DJI Fly.
The default control mode of the remote controller is Mode 2. In this manual, Mode 2 is used as the
example to illustrate how to use the control sticks.
Right StickLeft Stick
Turn RightTurn Left
Up
Down
RightLeft
Up
Down
Turn RightTurn Left
RightLeft
Forward
Backward
Left Stick Right Stick
Forward
Backward
Right Stick
Up
Down
Forward
Backward
Left Stick
Turn RightTurn Left
RightLeft
Mode 2
Mode 1
Mode 3

dji RC Specifications

General

Wi-Fi	Yes
Proper use	Universal
Product type	Remote control
Compatibility	DJI Mini 3 Pro DJI Mavic 3 DJI Mavic 3 Cine
Frequency band	2.400-2.4835; 5.725-5.850 GHz
Bluetooth version	4.2
Brand compatibility	DJI
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Maximum operating distance	15000 m
Equivalent Isotropically Radiated Power (EIRP)	26 dBmW
Display diagonal	5.5 \
Display brightness	700 cd/m²
Battery voltage	3.6 V
Battery capacity	5200 mAh
Battery life (max)	4 h
Battery recharge time	1.5 h
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	168.4 mm
Width	123.7 mm
Height	62.7 mm
Weight	390 g
